Ansung Model
|
BH660
|
BH760
|
BH860
|
| Digging Depth
|
6'6"
|
7'6"
|
8'9"
|
| Reach from Center Line of Swing Pivot
|
8'6"
|
9'4"
|
11.3"
|
| Loading Height (Bucket @ 60 degrees)
|
5'11"
|
6'7"
|
8.2"
|
| Maximum Leveling Angle
|
8°
|
8°
|
8°
|
| Swing Arc
|
180°
|
180°
|
180°
|
| Transport Height (Maximum)
|
5'6"
|
6'3"
|
7'6"
|
| Transport Overhang
|
3'8"
|
4'1"
|
4'10"
|
| Bucket Rotation
|
180°
|
180°
|
180°
|
| Stabilizer Spread (Down Position)
|
7'2"
|
7'2"
|
7'2"
|
| Stabilizer Spread (Up Position)
|
4'8"
|
4'8"
|
4'8"
|
| Angle of Departure
|
15°
|
20°
|
25°
|
| Undercut
|
1'8"
|
3'0"
|
3'1"
|
| Bucket cylinder digging force
|
2,920lb
|
3,080lb
|
3,670lb
|
| Dipper stick cylinder digging force
|
1,850lb
|
2,160lb
|
2,310lb
|
| Shipping weight (including bucket)
|
1,100lb
|
1,300lb
|
1,600lb
|
| Hydraulic Pressure requirements
|
2,350 psi.
|
2,350 psi.
|
2,350 psi.
|
| Recommended tractor HP requirement
|
15-30 HP
|
25-45 HP
|
45-65 HP
|
|
|
